Parameter name

AWT100-4G

AWT100-NB

AWT100-2G

AWT100-LoRa

AWT100-LW

Working frequency

LTE-FDD B1 B3 B5 B8

LTE-TDD B34 B38 B39 B40 B41
CDMA B1 B5 B8

GSM 900/1800M

H-FDD B1 B3 B8

B5 B20

GSM    850

EGSM 900

DCS    1800

PCS    1900

LoRa 460 ～
510MHz

Transmission rate

LTE-FDD Downstream rate
up to 150Mbps Uplink rate up to 50Mbps
LTE-TDD Downstream rate
up to 130Mbps Uplink rate up to 35Mbps
CDMA Downstream rate
up to 3.1Mbps Uplink rate up to 1.8Mbps
GSM Downstream rate up to 107Kbps Uplink rate up to
85.6Kbps

Downstream rate up to 25.2Kbps Uplink
rate up to 15.62Kbps

GPRS
Downstream rate up to 85.6kbps
Uplink rate up to 85.6kbps

LoRa 62.5kbps

Downstream

RS485 communication

Uplink

4G communication

NB-IoT
communication

2G
communication

LoRa
communication

SIM card
voltage

3V，1.8V

/

Working current

Static power consumption: ≤1W,

transient power consumption: ≤3W

Static power consumption：≤ 0.5W，
transient power consumption:≤
1W

Antenna
interface

50Ω/SMA(Female head)

Serial port
type

RS-485

Baud rate

4800bps、9600bps、19200bps、38400bps(default 9600bps)

Working
Voltage

DC24V or AC/DC220V①

Working
temperature

-10℃～55℃

Storage
temperature

-20℃～70℃

Humidity
range

0 to 95% non-condensing
