Technical parameter

Index

Accuracy class

Class 0.5

Input

Nominal value

BA20(Ⅱ)-AI

Current AC 0.5A, 50A, 200A, etc. AC 0～(0.5～200)A

BA50(Ⅱ)-AI


Current AC 60A, 300A, 600A, etc. AC 0～(60～600)A

BA50L(Ⅱ)-AI

Current AC 0.1A, 1A, etc. AC 0～(0.1～1)A

Overload

 Continuous 1.2 times, instantaneous current 10 times/1S

Absorbed power

≤1VA

Frequency response

25Hz～800Hz, especially suitable for industrial frequency
occasions

Outpu t

Nominal value

DC4～20mA, or 0～20mA, 0～5V, 0～10V① etc.

Load Resistance

When DC12V power supply, current output is ≤250Ω When DC24V power supply, current output is ≤500Ω,
When voltage output is ≥1KΩ

Communication

RS485 interface/Modbus-RTU②

Response time

≤400ms

Power suppl y

Voltage

 DC 12V or 24V

Power consumption

≤1W

Insulation resistance

＞100MΩ

Compressive strength

Between input/output and power supply 2.0KV/1min,
50Hz

Temperature Coefficient

-10℃～+55℃, ≤400ppm/℃

Envir onme nt

Temperature

Work: -10℃～+55℃ Storage: -25℃～+70℃

Humidity

≤93%RH, no condensation, no corrosive gas place

Altitude

≤2000m

Installation method

TS35 rail, or use screws to fix the cabinet
